PJ-A3020F-200 Measuring Projector
The PJ-A3000 Series vertical profile projectors are medium-size 11.8" (300mm) models that feature high versatility and easy operation.
Easy-to-read digital counters are located near the projection screen, thereby minimizing strain associated with excessive movement. A digital angle display eliminates the need to perform complex calculations.
Digital readout protractor screen facilitates angle measurement.
A floating table makes measuring quicker and easier.
PH-3515F Measuring Projector
TM-505 Measuring Microscope
The Mitutoyo 176-820A TM-A505B Toolmaker's Microscope has a 2 X 2"/ 50 X 50mm XY Stage Travel Range. This model includes Micrometer Heads. A compact microscope that is well suited for measuring dimensions and angles of machined metals. It can also be used to check the shape of screws and gears by attaching an optional reticle. its compact body make sit ideal for use on shop-floors with limited space. The eyepiece section of the optical tube incorporates a vernier protractor and angle measurement is performed easily by turning the protractor to align the cross-hair reticle with the workpiece image.
MF-B2017D Measuring Microscope
The Mitutoyo MF-B2017D , 176-868-10 Measuring Microscope expandability, such as when used in combination with Mitutoyo's vision unit to boost its performance or data management on a PC, promises further improved measuring efficiency. Features include observation with a clear and flare-less erect image and a wide field of view. Measuring accuracy that is the highest in its class (and conforms to JIS B 7153). The reflected and transmitted illumination unit is selectable from a high-intensity LED or halogen bulb. The variable aperture diaphragm allows observation measurement while suppressing light diffraction. The quick-release mechanism is useful for moving the stage quickly when measuring workpieces that are large in size or quantity. Has a coarse, fine feed handle that is standard on both sides and allow precise focus and observation measurement regardless of handedness. Includes a high-magnification eyepiece that can observe up to 2000x. This model has a 8x6.7"-200x170mm X XY Stage Travel Range, 16.1x13.4" 410x342mm XY Stage Top Size
LSM503S + LSM 5200 Laser Scan Micrometer
The Mitutoyo LSM-503S, 544-536 Laser Scan Micrometer is a High Accuracy non-contact measuring system. This model features a measuring range of .012-1.18" / 0.3-30mm *1] *This measuring range is available when set to "No extra-fine wire measurement" or "Edge specification" in the basic set up mode.
HR-530 RockwellHardness Tester
The new HR530 and HR530L Rockwell and Superficial hardness testers replace the HR521/L models. The new models include a color touch-screen controller. Four display types are available, as well as enhanced statistical graphing. ASTM D785 Part A and B now can be performed. The new HR530 includes common Light Force Brinell testing forces from 6.25 to 187.5kgf. All scales are shown on a single screen for ease of use.
HM-220 Type A Micro Vickers Hardness Testing Machine
Mitutoyo HM-220 Type A V/K, 810-400, 64AAB308P Micro Vickers Hardness Testing Machine is equipped with the latest technology electromagnetic force motor used in the loading mechanism that enables the test force to be freely selected (see test force specification) over the wide range of 0.4903mN to 19610mN (0.05gf to 2 kfg). It is also possible to freely set load dwell times. Now your desire for absolute control over the indentation size in Vickers hardness testing can be satisfied. The HM-200 Seris always offers the test force most appropriate for the specimen material and shape. The long working distance objectives used enable a very comfortable working distance between the objective and the specimen surface. This greatly reduces the possibility of collision between the specimen and the objective during focusing operations. Newly-designed "MH Plan" objectives are optimized for measuring indentation images. The lineup includes 6 types of long working distance objectives: 10X,20X,50X and 100X for measuring indentation images and 2X and 5X for enabling wide-range measurement around indentations. LEDs, which have a longer life, produce less heat, consume less power and are more energy efficient than incandescent bulbs, are employed for the illumination system. The motorized turret allows up to 4 objective lenses and 2 indenter assemblies to be mounted at the same time.
SJ-210 Surftest (Surface Roughness Tester)
The Mitutoyo SJ-210 Series 178, 178-561-01A Portable Surface Roughness tester combines high accuracy and measurement speed with numerous innovative features creating a new class leader in surface inspection. This model is has a Standard type Drive unit with 0.75mN detector measuring force. The SJ-210 can be operated easily using the buttons on the front of the unit and under the sliding cover. It can store up to 10 measurement conditions and one measured profile in the internal memory. Access to each feature can be password-protected, which prevents unintended operations and allows you to protect your settings. The display interface supports 16 languages, which can be freely switched. Also, in addition to calculation results, the Surftest SJ-210 can display sectional calculation results and assessed profiles, load curves and amplitude distribution curves.
SJ-310 Surftest (Surface Roughness Tester)
The Mitutoyo Surftest SJ-310, 178-573-02A is a compact, portable, easy-to-use surface roughness measurement instrument equipped with extensive measurement and analysis features. This model is a Retractable Type Drive unit with a 4mN Measuring Force. Features a large color graphic LCD touch-screen that provides excellent readability as well as a back-light for improved visibility in dark environments. The internal memory, password protection, multilingual support and stylus alarm are just a few things that make these highly functional. It also features enhanced power for making measurements on site possible. Also equipped with a highly-functional display unit containing an integrated high-speed printer.
